Contemporary 5 Bedroom Mansion - ID 25708
Description
Plan Description
This contemporary 5 bedrooms mansion plan is specifically designed for flood prone areas. The house is raised on stilts(columns) from the ground level.
On the first floor, you find an open-plan design spacious dining, and living room after entering from the entry porch. There is a large kitchen u-shaped with a kitchen island and adjacent to a pantry. All living spaces opens up to a big outdoor terrace area with access stairs to the ground level open dining. This allows for easy hosting of friends and parties while overlooking a beautiful garden and/ or swimming pool. The design also includes a more private family area as well as both a media room and an office. All bedrooms are ensuite with walk-in closets and placed on the first floor
The ground floor has a grand staircase to access the an entry porch on the first floor. Also there is a 3 car garage, an outside kitchen/bar with its own store and the open dining space, and bathroom.
Special design features such as burnt bricks cladding on top of regular concrete block walls give a beautiful natural finish. With its spacious layout, this contemporary 5 bedrooms mansion design offers plenty of seamless flow between indoor and outdoor spaces.
